Changeable superstructure

Municipal hook loader vehicle is used for transportation, unloading and reloading of standard containers of 4600-6900 mm length.

Technical specifications:
Chassis: MAN, Mercedes, Iveco, Volvo, Scania, DAF, Kamaz or other
Load capacity with stability legs drawn in: 5-13 t
Load capacity with stability legs drawn out: 2-9 t
Telescopic arm stroke: 1200 mm
Maximum tipping angle during discharge: 90°
Hydraulic stabilizer: 45°
Handling: from cabin and outside
Lifting container speed: app. 30-42 sec
Telescopic arm drawing in speed: app. 10-14 sec
Telescopic arm drawing out speed: app. 6-9 sec
Cabin protection: metal grid
Container handling: DIN 30720, DIN 30730
Other equipment: tool box
Technical specifications:
Chassis: MAN, Mercedes, Iveco, Volvo, Scania, DAF, Kamaz or other
Engine power: 260-290 kW
Rear axle: air suspension
Cabin: 1+2
Capacity: 18-20 t
Tipping angle: 49º
Commands: pneumatic,cabin controled
Weight: 2500-2650 kg
Other equipment: central lubricating system, all hydrocylinders with blocking valves, container fixing device
